KING EXTRA 160
от 50 в 115 HP
KING EXTRA 160
от 50 в 115 HP
Rear shredder with electronically balanced "Ventilator" rotor, available with hammers or knives. Recommended for shredding pruning and twigs up to 8 cm of diameter. The cutting equipment consists of a double frame built entirely in HARDOX®. 2 possible positions for the rear roller 1) self-cleaning 2) rear. The 3 rows of counter-knives installed inside guarantee excellent chopping quality in both positions of the roller.
Технический паспорт
Скачать лист каталогасоответствующие характеристики
DOUBLE FRAME IN HARDOX STEEL
FREE WHEEL IN THE GREARBOX
MECHANICAL SIDE SHIFT MOVEMENT WITH STEEL ROD
ROUNDED FRAME WITH ROUNDING ON THE OUTSIDE
ROTOR SPHERICAL ROLLER BEARINGS ON DOUBLE ROLLER ROW
PROTECTION FLAPS .6MM
преимущества
Frame with external side belvel
Rotor "ventilator" electronically balanced
Forest tool supports tools casted in Boron steel
TRIPLE STATIC KNIFE
Increased rows of counter knives hold the material in for more complete shredding.
Automatic belts tensioners
DOUBLE FLANGE IN THE ROTOR
Rear roller Prof ø 194mm
Back roller Prof Ø 195 MM with 4 bearings with tapered rollers, mud scraper and interchaneable central part with 2 positions:
1) Self-cleaning
2) Rear
EXTERNAL ROTOR SUPPORT IN PRESSED STEEL
The external rotor support allows the easy dismantling / replacement of the bearings and dust seals.
Free wheel in the group
Oscillating bearings with double rollers rack
оконечное оборудование
характеристики
- Machine
- DOUBLE FRAME IN HARDOX STEEL
- Standard
- ROUNDED FRAME WITH ROUNDING ON THE OUTSIDE
- Standard
- PROTECTION FLAPS .6MM
- Standard
- TRIPLE STATIC KNIFE
- Standard
- REAR ROLLER Ø 194 MM WITH 4 TAPER ROLLER BEARINGS DOUBLE POSITIONS: 1) SELF-CLEANING 2) REAR
- Standard
- REFLECTOR
- Standard
- REMOVABLE BONNET FOR INSPECTION
- Standard
- PROFESSIONAL BACK ROLLER Ø 194 MM WITH 4 BEARINGS WITH TAPERED ROLLERS, MUD SCARPER AND INTERCHANGEABLE CENTRAL PART WITH 2 POSITION : 1) SELF-CLEANING 2) REAR
- Опция
- PAIR OF WHEELS (INSTEAD OF THE STANDARD ROLLER)
- Опция
- LITTLE FRONT WHEELS
- Опция
- RAKES
- Опция
- PROTECTION CHAINS
- Опция
- SKIDS IN HARDOX STEEL
- Опция
- Transmission
- FREE WHEEL IN THE GREARBOX
- Standard
- ROTOR SPHERICAL ROLLER BEARINGS ON DOUBLE ROLLER ROW
- Standard
- VENTILATOR TYPE ROTOR
- Standard
- ROTOR TOOLS HOLDERS "FOREST TYPE"
- Standard
- PREDISPOSITION FOR CENTRAL GEARBOX
- Standard
- TOOLS CREWS Ø 20 MM IN STEEL 12.9
- Standard
- AUTOMATIC BELT TENSIONER
- Standard
- CENTRAL GEAR BOX
- Опция
- PTO SHAFT
- Опция
- SUPPLEMENT FOR ROTOR WITH KNIVES
- Опция
- 3 POINT HITCH
- MECHANICAL SIDE SHIFT MOVEMENT WITH STEEL ROD
- Standard
- HYDR. SIDE SHIFT REALIZED THROUGH FUSIONWITH NYLON BUSHINGS AND HARDENED AND CHROMED PIPES CAT.I-II
- Опция
- MECHANICAL SIDE SHIFT MOVEMENT IN CAST IRON WITH NYLON BUSHINGS AND HARDENED CHROMED STEEL ROD CAT. I-II
- Опция
- ACCESSORIES FOR BETWEEN ROWS/ORCHARDS/TREES
- FLAIL-D
- Опция
